1.3*H2.1mm Pogo pin DP132117-1

Model: dp132117-1

Category Pogo Pin
Views 45
Updated 2026-10-08
Images 6 Photos

📞 Get Quote ✉️ Email Inquiry 💬 QQ Online 📄 PDF Data Download

★ Product Introduction

Barrel material：Brass C3604/Brass C6801/Becu

Plunger material：Brass C3604/Brass C6801/Becu

Spring material：SUS304/SWP/Becu

Plunger plating spec：10u“ min. Au over 50-100u" Ni

Barrel plating spec：4u“ min. Au over 50-100u" Ni

Contact resistance：100 mohm max.

Rating current：1-2A AC/DC

Rating voltage：DC24V

Specifications
Description
Applications
Product Photos

Barrel material	Brass C3604/Brass C6801/Becu
Plunger material	Brass C3604/Brass C6801/Becu
Spring material	SUS304/SWP/Becu
Plunger plating spec	10u“ min. Au over 50-100u" Ni
Barrel plating spec	4u“ min. Au over 50-100u" Ni
Rating current	1-2A AC/DC
Rating voltage	DC24V
Contact resistance	100 mohm max.
Durability	10000-100000 cycles
Salt spray	48 hours min. RoHS and REACH compliant
Withstanding high temperature	260℃/10s

Model dp132117-1 1.3*H2.1mm Pogo pin DP132117-1 is a high-performance Pogo Pin manufactured by Shenzhen Wizconn Technology (WIZ-CONN), produced under strict ISO9001:2015 quality system for reliable electrical interconnection in consumer electronics, smart wearables, industrial automation and automotive applications. Key specifications include Barrel material. RoHS and REACH compliant. Salt spray rating 24–48 hours min. Mechanical durability up to 10,000+ cycles. Multiple plating options available to meet high durability / high current requirements.

WIZ-CONN also offers full custom Pogo Pin engineering services including pin layout, working height, current rating, SMT/THR assembly and packaging. Contact us for samples and quotations.

✅ Consumer electronics: smartphones, TWS earbuds, smart speakers, tablets, laptops

✅ Wearables: smart watches, fitness bands, VR/AR headsets, health monitoring devices

✅ New energy & automotive: EV BMS modules, car infotainment, in-vehicle charging

✅ Industrial & medical: handheld terminals, POS devices, portable medical instruments, sensors

✅ Smart home & IoT: smart locks, routers, wireless charging pads, security cameras
