2.8*H22.0mm Pogo pin FP282215-1

Model: fp282215-1

Category Pogo Pin
Views 45
Updated 2026-10-08
Images 5 Photos

📞 Get Quote ✉️ Email Inquiry 💬 QQ Online 📄 PDF Data Download

★ Product Introduction

Barrel material：Brass C3604/Brass C6801/Becu

Plunger material：Brass C3604/Brass C6801/Becu

Spring material：SUS304/SWP/Becu

Plunger plating spec：1u“ min. Au over 50-100u" Ni

Barrel plating spec：1u“ min. Au over 50-100u" Ni

Contact resistance：50 mohm max.

Rating current：3A AC/DC

Rating voltage：DC12V

Specifications
Description
Applications
Product Photos

Barrel material	Brass C3604/Brass C6801/Becu
Plunger material	Brass C3604/Brass C6801/Becu
Spring material	SUS304/SWP/Becu
Plunger plating spec	1u“ min. Au over 50-100u" Ni
Barrel plating spec	1u“ min. Au over 50-100u" Ni
Rating current	3A AC/DC
Rating voltage	DC12V
Contact resistance	50 mohm max.
Durability	10000-100000 cycles
Salt spray	24 hours min. RoHS and REACH compliant
Withstanding high temperature	260℃/10s

Barrel material：Brass C3604/Brass C6801/Becu
Plunger material：Brass C3604/Brass C6801/Becu
Spring material：SUS304/SWP/Becu
Plunger plating spec：1u“ min. Au over 50-100u" Ni
Barrel plating spec：1u“ min. Au over 50-100u" Ni
Rating current：3A AC/DC
Rating voltage： DC12V
Contact resistance：50 mohm max.
Durability： 10000-100000 cycles
Salt spray：24 hours min.
RoHS and REACH compliant
Withstanding high temperature: 260℃/10s

✅ Consumer electronics: smartphones, TWS earbuds, smart speakers, tablets, laptops

✅ Wearables: smart watches, fitness bands, VR/AR headsets, health monitoring devices

✅ New energy & automotive: EV BMS modules, car infotainment, in-vehicle charging

✅ Industrial & medical: handheld terminals, POS devices, portable medical instruments, sensors

✅ Smart home & IoT: smart locks, routers, wireless charging pads, security cameras
